CG23M Bookshelf Speaker
Like the CG3M, the CG23M is an audio breakthrough. The CG23M sets a new standard, achieving performance miles beyond its price. Designed to master the stringent demands of two-channel, the CG23M’s exceptional clarity, remarkable resolution, and spectacular imaging, provides an experience unparalleled in realism. Never before has such a small, modestly-priced speaker sounded so spacious, three-dimensional, and true-to-life.
*The CG23M can be placed vertically or horizontally and provides the subtle presence desired from a center channel.
CG23M Bookshelf Speaker
SUPERIOR BUILD FROM TOP TO BOTTOM
Compact bookshelf and “LCR” models, available for flexible multi-channel options.
*NEW* Scratch resistant matte finish blends into any environment
Patented Compression Guide tuning for extended bass response
Improved efficiency over original gloss models
Audiophile grade crossover components
Mineral-filled woven aramid fiber cones
Recommended for use with amplifiers rated from 40W to 150W per channel
FLEXIBLE MOUNTING SOLUTIONS
COMPRESSION GUIDE TECHNOLOGY
THE ACE UP OUR SLEEVE
Compression Guide technology is the difference between RSL speakers and all other speakers. It's the secret behind our award-winning sound. It's why RSL speakers sound so clear and incredibly realistic.
STANDARD SPEAKERS & SUBWOOFERS
They
Work?
Ours
Work?
RSL SPEAKERS & SPEEDWOOFERS
SPECIFICATIONS
- Woofer: Dual 4” mineral-filled woven aramid fiber cones with Y35 high-grade ferrite magnets
- Tweeter: 1” silk dome, neodymium magnet
- Frequency Response: 80-20,000 Hz ± 3db
- Nominal Impedance: 4 ohms
- Recommended Impedance setting for amplifiers: 6 or 8 ohms
- Sensitivity: 89 dB SPL @ 1W/1M
- Recommended Power: 40-150 watts
- Crossover Frequency: 2,800 Hz
- Crossover Slope: Asymmetric 12 dB/octave
- Crossover Parts: Air-core Inductors, poly capacitors, and gold-plated binding posts
- Tuning Method: Compression Guide™
- System Resonance: 75 Hz
- Weight: 10 lbs.
- Dimensions (vertical): H: 16” W: 6” D: 6 1/2 “(Without grille 6 ”)
