Speedwoofer 12S

Features:

500 watts RMS / 1550 watts peak
Die-cast aluminum frame 12” woofer w/ dual-mirrored true Nomex™ spiders
Proprietary multi-function PCB Heat Sink/EMI Shield
Deep bass extension down to 16Hz! (anechoic)
4 DSP Modes - Movie, Music, Reference, Boundary
New rear-vented Compression Guide™ tuning
Convenient IR remote control functionality
New AR4 - External Wireless option available
Independent adjustable line-level high-pass outputs (30-250Hz)
Warranty: 5-year woofer / 3-year electronics
ALL SPEEDWOOFERS INCLUDE A COLOR-MATCHED GRILLE

Terms & Conditions:

Free shipping within the 48 states!
Highly discounted international shipping available
30-day in-home trial period
Cancellations must be requested prior to shipping (a 3.5% cancellation fee will apply)
$150 flat-rate return fee per Speedwoofer 12S from the 48 states. (measure your space!)

NOTE FROM RSL TEAM

Note from RSL Team

Help us to reduce or eliminate the return fee!
Our return fee is in place for the sole purpose of protecting the Speedwoofers’ industry-leading performance and pricing. The cost of one-way shipping for a Speedwoofer ranges from $40 to $150. Double that and add a substantial cost for repackaging and recertification, and it becomes obvious why returns have such an impact. This holds true for ALL consumer-direct products. So please keep this in mind wherever you shop, and support us in the fight to eliminate the Speedwoofer return fee.

The two leading causes of Speedwoofer returns continue to be simple over-ordering and spatial constraints. As such, we would like to ask you to kindly consider the following before ordering:

Measure twice, order once! Please measure your intended subwoofer locations to ensure the Speedwoofer will fit. Then measure again!
Check with your family members! Make sure the Speedwoofer’s aesthetics are acceptable for your home.
Order LESS! That might sound strange, but if you aren’t sure how many Speedwoofers you’ll need, start with just one. We know that the affordable price makes multiples even more compelling. However, we would rather build your system to where it needs to be, than have you pay return fees later.
Ask for guidance! We are always happy to answer questions and make recommendations. No question is too big or small.

We’d love to see the return fees disappear. Together, we can make it happen!

Thank you and best regards,
The RSL Team

Color: Black (Matte)

$799each

Condition

Factory New A. Just like new B. Minor blemishes C. Noticeable blemishes

View Specifications

Product variants

Speedwoofer 12S

Product Preview

Size

Frequency Response

Unboxing

UNBOXING YOUR SPEEDWOOFER12S

My first musical sub

I have had 4 subs in the last 25 years, all name brand, mainly for home theater but also for my dedicated music system. I thought they were mainly to bring out drama in movies (the thump of an explosion or other loud sounds) and accentuate the bass drum in music. I always kept them so low you could barely hear them so they didn’t dominate the music. The Speedwoofer is something entirely different. Once set up and adjusted, It enhances the music, it doesn’t stand out and call attention to itself. The double bass in jazz now sounds like a real double bass, with all notes, including the lowest, clearly heard. Ditto for drums, you hear the full set. It also greatly enhances classical music, again by bringing in the lowest notes and harmonics in a way that sounds natural. I am very impressed, I never knew that a sub was so important to fully enjoying music.

LOVE IT!

Upgraded to go with my Marantz + DEF TECH towers & satellites. Such an improvement. The range is amazing and makes such a difference.
Delivery was quick, too.

The best subwoofer that I have ever owned. Packaged very well and it's performance is off the charts!

Great customer service. Amazing product!

This subwoofer is part of my first home audio sound system. The customer service department was patient with me and essential in helping me get everything up and running. I found this subwoofer online after going to several electronic stores and becoming disappointed with what was offered. After doing research online I came across a lot of positive feedback on this woofer so I gave it a try. I am blown away by the awesomeness of this subwoofer!!! Additionally all my guests have designated my home as the place to come game and watch movies!

Awesome sound

It took me a little over a month to get my house ready for the system but just got it installed and they are not even broke in yet fully and they sound amazing in an open room the sound fills the room and is perfectly balanced. I have already recommended them to a few friends and they are considering it after hearing it.

SPECIFICATIONS

Speedwoofer 12S

Frequency Response:
- Reference Mode (anechoic): 16 Hz-200 Hz ± 3db (SEE GRAPH FOR VARIOUS DSP RESPONSES)
Woofer:
- 12” 500+ watt rated woofer
- 4 ohm nominal Impedance
- Proprietary RSL Die-cast aluminum frame with dual spider integration
- Klippel optimized linear magnet motor and matched suspension
- High-Excursion FEA optimized design motor structure
  - Integral VC Heat Sink/Inductance Control Sleeve
  - 1008 low-carbon steel motor parts (T-yoke and field plate)
  - Premium grade dual-stacked ceramic magnets
  - Ultra-high Temp (>200° C), Multi-layer Copper Voice Coil
- Dual-mirrored, High yield fatigue-resistant Nomex™ spiders
- Integrated Dual Spider spacer clamp ring
- Kevlar™ reinforced paper cone with full anodized aluminum dust cap
- High durability NBR surround
- High duty cycle periodically stitched flexible tinsel lead wire with strain relief features
Enclosure:
- Scratch and fingerprint resistant textured matte finish
- Front multi-segment LED display/indicator (Volume, Mute, & DSP MODE)
  - Display sleeps after ~10 sec. of inactivity
- Rear-vented Compression Guide™ tuning with turbulent free slot port
- Internal structural reinforcement (Side to side, front to back, and top cross-bracing)
- ¾” thick MDF panels with dado reinforced joints plus corner bracing
- Laminated 1” front woofer baffle
- Internally optimized damping
- Removable cloth grille
XDR Series Amplifier:
- IR Remote Control (Power Toggle, Volume +-, Mute, DSP Mode direct select (Reference, Music, Movies, Boundary)
- External 3.5mm IR input for wiring external IR sensor (eye)
- 500 watts RMS < 1% THD
- 1550 watts peak
- Patent Pending HSS™ Heat Sink/Shield Technology for greater thermal efficiency and capacity
- DSP Modes – Reference, Music, Movies, Boundary (Rear LED indicator matches front display)
  - Reference – Minimal EQ processing, “natural” response for ideal transient performance
  - Music – Shelved response for extension, but with good upper bass impact
  - Movies – Enhanced output between 25-35Hz to augment low frequency content at low levels
  - Boundary – “Neighbor friendly”…Reduced lower frequencies to limit rumble through walls
- Integrated double-precision 56-bit, 50 MIPS DSP processor
- Intelligent class D topology, >85% Efficiency
- Signal to noise ratio: >85dB
- Auto-ON Threshold: 3mV
- Auto-OFF: ~20 minutes (no signal)
- Stand-by power consumption: ~1 watt
- Power Input: Selectable 110/230VAC 50-60Hz switch
- Low EMI design, CE & C-Tick compliant
- Gold-plated RCA Line level inputs and RCA High-pass signal outputs (high-pass is adjustable and can be bypassed)
- Speaker level inputs (Gold-plated, 5-way binding posts)
- Chassis ground screw
- USB Power port, easily connect external AR-4 2.4GHz wireless receiver
Low Pass Crossover Frequency: 30-250 Hz variable (with integrated bypass switch)
Low Pass Crossover Slope: 24 db/oct.
High Pass RCA Output Crossover Frequency: 30-250 Hz variable (with integrated bypass switch)
High Pass RCA Output Crossover Slope: 24 db/oct.
Phase Control: 0 to 180 continuously variable
Power Input: 115V, 60Hz, 230V, 50/60Hz AC
Feet: Includes 4 rubber feet
Dimensions with Feet: H: 22 1/4” W: 18 7/8” D: 22 1/8”
Weight: 82 lbs.
Shipping Dimensions: H: 29” W: 25” D: 29”
Shipped Weight: ~106 lbs.
Fuse: 115V (T6.3AL/250V) – 230V (T3.15AL/250V)
