Speedwoofer 12S

Features:

  • 500 watts RMS / 1550 watts peak
  • Die-cast aluminum frame 12” woofer w/ dual-mirrored true Nomex™ spiders
  • Proprietary multi-function PCB Heat Sink/EMI Shield
  • Deep bass extension down to 16Hz! (anechoic)
  • 4 DSP Modes - Movie, Music, Reference, Boundary
  • New rear-vented Compression Guide™ tuning
  • Convenient IR remote control functionality
  • New AR4 - External Wireless option available
  • Independent adjustable line-level high-pass outputs (30-250Hz)
  • Warranty: 5-year woofer / 3-year electronics
  • ALL SPEEDWOOFERS INCLUDE A COLOR-MATCHED GRILLE

Terms & Conditions:

  • Free shipping within the 48 states!
  • Highly discounted international shipping available
  • 30-day in-home trial period
  • Cancellations must be requested prior to shipping
  • A 3.5% cancellation fee will apply
  • $150 flat-rate return fee per Speedwoofer 12S from the 48 states. (measure your space!)
NOTE FROM RSL TEAM

Note from RSL Team

x

Help us to reduce or eliminate the return fee!
Our return fee is in place for the sole purpose of protecting the Speedwoofers’ industry-leading performance and pricing. The cost of one-way shipping for a Speedwoofer ranges from $40 to $150. Double that and add a substantial cost for repackaging and recertification, and it becomes obvious why returns have such an impact. This holds true for ALL consumer-direct products. So please keep this in mind wherever you shop, and support us in the fight to eliminate the Speedwoofer return fee.

The two leading causes of Speedwoofer returns continue to be simple over-ordering and spatial constraints. As such, we would like to ask you to kindly consider the following before ordering:

  • Measure twice, order once! Please measure your intended subwoofer locations to ensure the Speedwoofer will fit. Then measure again!
  • Check with your family members! Make sure the Speedwoofer’s aesthetics are acceptable for your home.
  • Order LESS! That might sound strange, but if you aren’t sure how many Speedwoofers you’ll need, start with just one. We know that the affordable price makes multiples even more compelling. However, we would rather build your system to where it needs to be, than have you pay return fees later.
  • Ask for guidance! We are always happy to answer questions and make recommendations. No question is too big or small.

We’d love to see the return fees disappear. Together, we can make it happen!

Thank you and best regards,
The RSL Team

Color: Black (Matte)
$799each
Condition
Free Shipping within the Continental US
* TAXES (GST) INCLUDED *
If you’re not thrilled with an RSL product within 30 days, return it hassle-free. Just contact us and we will email a return label with instructions. A return fee will apply to each Speedwoofer, wireless device, and amplifier / AV receiver included. (For International Returns are different, call us.) International returns are to be arranged and paid by the customer. RSL does not cover international return shipping, or shipping insurance.
All products ship for free to the contiguous 48 States. This includes all Speedwoofers, System Packages, A/V Receivers, Individual Speakers, and Accessories!
We’re ready to answer your questions, provide support, and even help you plan your home theater. Just give us a call at 800-905-5485 or email us at sales@rslspeakers.com.
Our average turnaround time is one business day. Orders received before 11AM Monday – Friday often ship same day!
A $150 flat-rate return fee applies per Speedwoofer 12S returned from the 48 states. Returning a defective item under warranty for replacement does not carry a return fee, as the return label will be supplied by RSL (U.S. Only)
All Speedwoofer 12S's include a 3-year amplifier warranty, and a 5-year warranty on the woofer and enclosure. If something isn't performing like new throughout the warranty period, please don't hesitate to email us for assistance!
We offer highly discounted shipping rates to virtually anywhere outside of the contiguous US via premium air-freight shipping.

Speedwoofer 12S

Product Preview
Size
Frequency Response
Unboxing
UNBOXING YOUR SPEEDWOOFER12S

Customer Reviews

Based on 52 reviews
98%
(51)
2%
(1)
0%
(0)
0%
(0)
0%
(0)
j
josh h.
rsl speedwoofer 12

this speedwoofer is amazing. enclosure and porting tuning absolutely exceeded my expectations and easily overpowers my theatre space. would definitely purchase the speedwoofer 10 to compliment the full range of sound the 12 has already accomplished. great value for the money.

J
Jim H.
Great product great service

I had trouble getting my subwoofer to work at all even though it powered on. I spent time on the phne with customer service attempting varouis fixes. I have a 1970s Marantz system and somehow after unplugging and plugging cords into variouus ports the speaker started wrorking. It was great working the customer support. The speaker has added a whole new dimension to my music.

M
Michael F.
Nice upgrade!

I had purchased a 12S to replace a pair of old Polk PSW505(s). I was quite impressed with the room filling sound this produces. With the finely adjustable phase control, i had no problems getting the 12S to blend in nicely. Many props to the sound and build quality!

D
Dale K.
Great Subwoofer

I have had this subwoofer for about a month and it is great. No complaints from me. I did experience some shipping damage but working with Joe in customer service was a pleasure. The damage was cosmetic and did not affect performance at all.

D
D L.
Can’t beat it for the price/performace

If you can’t deal with the larger cabinet and are in this budget range. You can’t get any better sound and quality.

SPECIFICATIONS

Speedwoofer 12S
  • Frequency Response:
    • Reference Mode (anechoic): 16 Hz-200 Hz ± 3db (SEE GRAPH FOR VARIOUS DSP RESPONSES)
  • Woofer:
    • 12” 500+ watt rated woofer
    • 4 ohm nominal Impedance
    • Proprietary RSL Die-cast aluminum frame with dual spider integration
    • Klippel optimized linear magnet motor and matched suspension
    • High-Excursion FEA optimized design motor structure
      • Integral VC Heat Sink/Inductance Control Sleeve
      • 1008 low-carbon steel motor parts (T-yoke and field plate)
      • Premium grade dual-stacked ceramic magnets
      • Ultra-high Temp (>200° C), Multi-layer Copper Voice Coil
    • Dual-mirrored, High yield fatigue-resistant Nomex™ spiders
    • Integrated Dual Spider spacer clamp ring
    • Kevlar™ reinforced paper cone with full anodized aluminum dust cap
    • High durability NBR surround
    • High duty cycle periodically stitched flexible tinsel lead wire with strain relief features
  • Enclosure:
    • Scratch and fingerprint resistant textured matte finish
    • Front multi-segment LED display/indicator (Volume, Mute, & DSP MODE)
      • Display sleeps after ~10 sec. of inactivity
    • Rear-vented Compression Guide™ tuning with turbulent free slot port
    • Internal structural reinforcement (Side to side, front to back, and top cross-bracing)
    • ¾” thick MDF panels with dado reinforced joints plus corner bracing
    • Laminated 1” front woofer baffle
    • Internally optimized damping
    • Removable cloth grille
  • XDR Series Amplifier:
    • IR Remote Control (Power Toggle, Volume +-, Mute, DSP Mode direct select (Reference, Music, Movies, Boundary)
    • External 3.5mm IR input for wiring external IR sensor (eye)
    • 500 watts RMS < 1% THD
    • 1550 watts peak
    • Patent Pending HSS™ Heat Sink/Shield Technology for greater thermal efficiency and capacity
    • DSP Modes – Reference, Music, Movies, Boundary (Rear LED indicator matches front display)
      • Reference – Minimal EQ processing, “natural” response for ideal transient performance
      • Music – Shelved response for extension, but with good upper bass impact
      • Movies – Enhanced output between 25-35Hz to augment low frequency content at low levels
      • Boundary – “Neighbor friendly”…Reduced lower frequencies to limit rumble through walls
    • Integrated double-precision 56-bit, 50 MIPS DSP processor
    • Intelligent class D topology, >85% Efficiency
    • Signal to noise ratio: >85dB
    • Auto-ON Threshold: 3mV
    • Auto-OFF: ~20 minutes (no signal)
    • Stand-by power consumption: ~1 watt
    • Power Input: Selectable 110/230VAC 50-60Hz switch
    • Low EMI design, CE & C-Tick compliant
    • Gold-plated RCA Line level inputs and RCA High-pass signal outputs (high-pass is adjustable and can be bypassed)
    • Speaker level inputs (Gold-plated, 5-way binding posts)
    • Chassis ground screw
    • USB Power port, easily connect external AR-4 2.4GHz wireless receiver
  • Low Pass Crossover Frequency: 30-250 Hz variable (with integrated bypass switch)
  • Low Pass Crossover Slope: 24 db/oct.
  • High Pass RCA Output Crossover Frequency: 30-250 Hz variable (with integrated bypass switch)
  • High Pass RCA Output Crossover Slope: 24 db/oct.
  • Phase Control: 0 to 180 continuously variable
  • Power Input: 115V, 60Hz, 230V, 50/60Hz AC
  • Feet: Includes 4 rubber feet
  • Dimensions with Feet: H: 22 1/4” W: 18 7/8” D: 22 1/8”
  • Weight: 82 lbs.
  • Shipping Dimensions: H: 29” W: 25” D: 29”
  • Shipped Weight: ~106 lbs.
  • Fuse: 115V (T6.3AL/250V) – 230V (T3.15AL/250V)

FREQUENCY RESPONSE

A subwoofer for ANY room size.
